terça-feira, 29 de abril de 2008

Imagem do Dia


As ultimas Sportsters carburadas que sairam, ano 2005/2006, levavam este carburador Keihin CV40.

Mais sobre Carburadores:

domingo, 27 de abril de 2008

Motorcycle Repair Course

Tem de tudo, um manancial de informações. Prá querer ter conexão banda larga na oficina...


sexta-feira, 25 de abril de 2008

Evel Knievel

Evel Knievel
AKA Robert Craig Knievel

Born: 17-Oct-1938
Birthplace: Butte, MT
Died: 30-Nov-2007

Robert "Evel" Knievel said that he was first inspired to jump over things when he was eight years old, attending an auto daredevil show.

At 13, he obtained his first motorcycle, but crashed it while attempting a stunt.

As a young man he was a competitive ski jumper and minor league hockey player, and he had numerous encounters with law enforcement over petty crimes. In 1953 he was charged with kidnapping Linda Bork, who became his wife six years later.

After injuring himself in a motorcycle race, he worked as an insurance salesman, then sold motorcycles before forming a traveling show called Evel Knievel's Motorcycle Daredevils in the mid-1960s. The show featured Knievel and cohorts jumping through firewalls, over rattlesnakes, and other crowd-pleasing stunts, but it was soon clear that he was the star, and Knievel began working alone. Longer and more spectacular jumps led to higher prices for promoters and ticket-buyers, so his jumps grew longer, more implausible and ill advised.

In 1967 he jumped more than 150 feet across the fountains at Caesars Palace in Las Vegas, in 1970 he jumped 13 cars in Seattle, and in 1971 he flew over 19 cars in Ontario, California. Later that year he had his first high-profile wreck, failing to jump 13 Pepsi trucks in Yakima, Washington.

He hired famed attorney Melvin Belli to try to secure government permission to jump the Grand Canyon, but was rebuffed. Instead he attempted to jump the Snake River Canyon in Idaho in 1974. It was his most celebrated jump, with some 16,000 people watching as he seemed to clear the gorge but was then blown backwards by a prematurely-deployed parachute, and drifted down to the water's edge with minor injuries.

In 1975 he cleared 13 double-decker buses in London, but broke his pelvis in a rough landing and informed reporters he would never jump again. Five months later, he jumped 14 Greyhound buses in Ohio.

In 1975, he again announced his retirement from daredevil antics after receiving a serious injury during a Chicago jump over a tank filled with live sharks. But the retirement was short-lived, and he continued making stunt jumps until 1980.

Reports on Knievel's antics usually mentioned how many bones he had broken, but the count was not necessarily reliable.

His broken bones numbered 56 in media accounts of the Chicago shark jump, and over subsequent years the number varied from the low 30s to over 100.

In 1978 he spent six months in Los Angeles County Jail for the baseball-bat beating of Sheldon Saltman, author of a Knievel biography the stuntman did not enjoy reading. In 1994 he was arrested for beating the woman who would become his second wife five years later.

In 1998 he was pinned under a motorcycle in his workshop, and rescued only after neighbors heard his cries for help. In 1999 he received a liver transplant after contracting hepatitis C. In 2007 he sued Kanye West over the rapper's video "Touch the Sky", which showed West in Knievelesque garb pretending to perform a motorcycle jump over a canyon. The lawsuit was settled with a handshake three days before Knievel's death.

sexta-feira, 18 de abril de 2008

E Cafe japonesa...

As CBs são excelentes plataformas para Cafe.

O mago das SeteGalo, as CB750. Carpy.


Cafe italiana

Além das Inglesas, motocicletas Italianas prestam-se bem ao estilo Cafe.
Simples de entender, duas nações com longa história em corrida de motocicltas.

Cafe-racers - Referências

Cafe-racers seriam, por sua origem, basicamente motocicletas inglesas da década de 50/60. Assim como puristas consideram que apenas as Harleys seriam boas bases para a construção de choppers, Norton, Triumph, Vincent, BSA, para muitos, são a pura excencia das Cafe.

mais referencias em:



The Cult of the Ton up Boy

Convém ver as sequencias no you tube.





A Café racer is a type of motorcycle as well as a type of motorcyclist.

Both meanings have their roots in the 1960s British counterculture group the Rockers or the Ton Up Club, although they were also common in Italy, amongst Italian motorcycle manufacturers and other European countries.

Rockers were a young and rebellious Rock and Roll counterculture that wanted a fast, personalized and distinctive bike to travel between transport cafés along the newly built arterial motorways in and around British towns and cities. The goal of many was to be able to reach 100 miles per hour (called simply "the ton") along such a route where the rider would leave from a cafe, race to a predetermined point and back to the cafe before a single song could play on the jukebox, this was called record-racing.

Riders rejected the large transportation-oriented motorcycles of the time by taking these motorcycles and removing any unnecessary parts off them. The bikes had a raw, utilitarian and stripped-down appearance while the engines were tuned for maximum speed.

Because speed was valued more than comfort, bikes were fitted with single seats and low handle bars, such as ace bars, or even one-sided clip-ons mounted directly onto the front forks for more precise control and to escape the wind.

Distinctive half or sometimes full race fairings, and large, hand-made, aluminium racing petrol/gas tanks were frequently left unpainted. Swept-back exhausts and rearset footpegs were used to give better clearance whilst leaning through corners at speed.

Now this definition does not begin to describe the true feeling and spirit of these early motorbike pioneers.

The essence and freedom of these trailblazers has transcended into a new generation of modern day Café Racers.

Café da Manhã

Norton Commando 750

Mais no decorrer do dia...

quarta-feira, 16 de abril de 2008

Imagem do Dia

Got Salt ?

David Mann

Em 1971 a revista Easy Riders lançou um anuncio em busca de artistas para ilustrar suas páginas. O anuncio foi respondido por um artista de Kansas City, chamado David Mann.
O resto é história. Ele enfeitou a Easy Riders por décadas, sempre captando profundamente o que se passava na cabeça dos motociclistas.

Como uma imagem vale mais que mil palavras, seguem as imagens...

Ferramentas HD - o essencial

Muitos perguntam o que seria um bom set de ferramentas para se levar na moto.

As opiniões variam demais. Tem os minimalistas que dizem "o Cartão de Crédito", até um que fez questão de levar um mini-compressor de ar para "o caso de furar um pneu".

Em viagem de moto, less is more, sempre.

Então, segue uma lista possivel de ser levada sem ser exagerada, mas que pode te tirar de uns apertos básicos.

Lanterna com pilhas (prefiro as lanternas de colocar na testa, tipo "mineiro")
Alicate de pressão

Alicate pequeno
Chave de catraca 3/8"
Socketes de vela de 5/8" e 13/16"
Chaves de boca combinadas 3/8", 7/16", 1/2", 9/16", 5/8", 3/4", 10mm

Jogo de 9 Chaves Allen
Jogo de 7 Chaves Torx (T10 a T40)
Chaves Phillips #1 e #2

Chaves de Fenda pequena e media
Silver Tape

E não esqueça o Cartão de Crédito/Saque 24hs. No fim são as melhores ferramentas.

Marquem na Agenda

Festival de Motos Classicas - Encontro de Tiradentes

25 a 29 de Junho, em Tiradentes - MG

É considerado por muitos o melhor encontro de motociclistas do Brasil.

As ruas de Tiradentes não são as mais fáceis para pilotar motos pesadas, paralelepipedos e subidas e descidas ingremes. E fica lotado na época do Encontro.

Assim, cuidado extra prá não derrubar moto dos outros.


Frisco Hells Angels

Piadinha prá começar o dia

Parados no sinal estão:

de um lado uma HD Old School com seca-suvado e um cara todo tatuado vestindo preto;

de outro, uma Ninja com um Jaspion em cima.

O cara da Ninja: - Legal esse guidon... Quando a polícia te para você já está com as mãos para cima...

E o cara da HD:- Melhor as mãos, que a bunda...

terça-feira, 15 de abril de 2008

Imagem do Dia

Got Salt ?

Marquem na Agenda

16, 17 e 18 de Maio. Petropolis.


Não é muito Moto Clube que tem essa idade. Vale comemorar.
Um encontro de Motociclistas para Motociclistas.

Pedala, Castrol !

Imagens raras - 1920 Board Track Motorcycle Racing.


Parafraseando Kelly Key: "Baba baby"

Cheap Kustoms - Estatutos de Utilização

A idéia é ser um lugar para trocar idéias sobre veiculos vintage, motos (cafe racers, choppers, bobbers, de competição ou off road), carros (hot rods, muscles, antigos e de competição), ou qualquer outro assunto interessante.

"Aceitamos qualquer um de mente aberta, sem pré ou pós conceitos, interessados em passar momentos agradáveis em boa companhia." (parece coisa de clube de swing)

Poetas, boêmios, pilotos e putas são bem vindos.

Otários serão devidamente ridicularizados, mas também são bem vindos.

Como somos ecléticos e tecnologicamente avançados, traga seu i-pod e nutra-nos com sua trilha sonora. Pagode, axé e sertanejo serão considerados ofensa pessoal, fora isso, quase tudo é bem vindo.

Todas as ferramentas estão disponiveis para uso de todos. Mas devem ser devidamente limpas e guardadas. Aceito contribuições.

Welcome To The Jungle !!!


Cheap Kustoms
Vintage Vehicles
by Lord Of Motors

Lord Of Motors

E agora, enfim, vamos nos apresentar.

Chamam-me Lord. Lord of Motors.

Hot Rodder, bike rider, master builder.

Bemvindos ao Meu Mundo.
Espero que divirtam-se.

segunda-feira, 14 de abril de 2008


Para começar com o pé direito, e sabendo que "Quem não conhece o passado não conhecerá o futuro", comecemos com a História da Harley Davidson Sportster. Ela será objeto de diversas postagens neste blog, e porque então não começarmos apresentando-a...


1952: The Model K Sport and Sport Solo motorcycles were introduced this year. They were all new designs. They featured styling and influence that was part 125 Model S, part W 45 Sidevalve and part FL 61 OHV Big Twin, with other innovations incorporated. The Model K was an exciting and different motorcycle. It represented the most technologically advanced and modern motorcycle that Harley Davidson had produced to date. Although based on the proven 45 Side Valve formula from 1929, the engine was an all new design. It featured larger cams, carburetor, and higher compression than the W. The engine and transmission now shared the same engine cases. The transmission had four speeds and a hand operated clutch. The K was the first Harley Davidson to incorporate modern hydraulic dampened suspension on both wheels, with telescopic forks in front and a rear swingarm and shock absorber combination. The K foot-shifted on the right and braked on the left not so much as to copy the British but to lay out the controls in anticipation of flat track racing.
Facts about the 1952 Model K: The engine had a relatively high (for a Side Valve) compression ratio of 6.5 to 1. The cylinder bore was 2-3/4" with a 3-13/16" stroke for a total displacement of 45.12 Cubic Inches. It came with an 1-1/2" Bore Linkert "Bombsight" carburetor Model M-53. The engine produced 30 horsepower. The motorcycle had a wheelbase of 56". Standard tires and wheels were Goodyear or Firestone and measured 19" by 3.25", front and rear. The gas tank held 4-1/2 gallons. The oil tank held 3 quarts. The transmission oil which was separate held 1-1/5 pints. Standard sprockets were Engine-30, Clutch-59, Countershaft-21, and Rear Wheel-51 teeth. Gear ratios were 1st- 12.37, 2nd- 8.74, 3rd- 6.21 with a final 4th- 4.77 to 1. Tire pressures were recommended at 20psi front and 22psi rear for a 150 lb rider. When this weight is exceeded by 50 lbs or more increase front pressure 1psi and rear 2psi for each additional 50 lbs. Spark Plug gap with circuit breaker (distributor) should be .025" to .030". Point gap is .022" Ignition timing is 19/64" BTDC, with the spark control in the fully advanced position. Cold Valve Tappet clearance is .004"-.005" on the intake tappets and .010"-.011" on the exhaust. Adjust every 1500 miles minimum. Forks hold 4-1/2 ounces dry or add 3-1/2 ounces after draining during regular service. These specs are for most K`s and remain the same unless noted later. 1952 Model K`s were available in the following standard colors: Tropical Green, Rio Blue, Persian Red, and Brilliant Black. Special colors at a slight extra charge were Metallic Bronco Bronze, White, and Metallic Marine Blue.
1952 and 1953 K Sport Models, (not KK), performance figures: The K was known to run the 1/4 mile in about 16.8 seconds at around 53 miles per hour and had a top speed of just over a hundred miles per hour flat out.


The 1953 K remained relatively unchanged. A faster acting throttle was installed. New saddlebags made of Royalite plastic were introduced along with a restyled Buddy Seat. Tires and wheels remained at 19" with the options being Goodyear, Firestone Champion or Firestone Sportsman with the front at 3.25" and the rear growing to 3.50" in width. A new Standard Solo Group was added to the option list which consisted of more cadmium plated and painted parts in place of chrome and subsequently a lower base price. The Model KK was introduced which was a factory performance enhanced model. The KK had much larger racing cams, carb modifications, head modifications and cylinder porting to match. It used the old WR racer's valves and guides and the new KR racer's lightened roller tappets. The cam set #25500-53 was also used later in the 1954, 55, and 56 KHK Super Sport Models. The standard colors for 1953 were Brilliant Black, Glacier Blue, Forest Green and Pepper Red. For a slight extra charge Cavalier Brown, Glamour Green and White were also available.

1954: The Golden Anniversary KH Sports and KHK Super Sports were big news for Harley Davidson and the motoring public. The popular Model K now evolved into the KH and later the KHK with many improvements. Foremost was the increase in engine size from 45.12 to 54.2 cubic inch displacement. This was achieved by increasing the stroke from 3-13/16" to 4-9/16" (4.562). To the best of my knowledge these were the longest stroke factory built Harleys to date. The flywheels are still available from Truett & Osborn in Wichita, Kansas. The new flywheels utilized tapered shafts and crankpins with retaining nuts, a much stronger system than the previous straight, pressed type. New rod bearing retainers were added for greater reliability. Engine cylinders were made taller to match the stroke increase and had redesigned ports and bigger intake valves. The KH had bigger cams and the KHK had the even larger racing type KK cams. These cams were larger than the ones in Brad Andres` 1955 National Championship KR Motorcycle. The KHKs were hand built factory Hot Rods that also benefited from extensive additional port work and head machining. The headwork increased flow and made room for the valves necessary due to the high-lift cams. Valve springs were changed to the KR racer type. A new Linkert M-53A1 carburetor was added to the package. All this translated into a motorcycle that now produced 38 Horsepower and 1/4 mile dragstrip times were over two seconds quicker than the standard K. The KH would now do the 1/4 in 14.75 seconds. I don`t have performance figures for the KHK but obviously they would be even better.
Now I would like to point out that several books often portray the K as being a sub-standard motorcycle, (in the power department), and not really even being acceptable until it received Overhead Valves and was called an XL. However a 1966 XLH took 15.5 seconds to do the 1/4, although a 1958 XLCH would run it in 14.25. The first Sportster in 1957 had only 7.5 to 1 compression and 40 Horsepower, then the 1958 was upgraded to 9 to 1 with bigger valves. Also the 58 XLCH was a lightweight stripped down motorcycle. No battery, etc. The point I`m making is that granted, the first year K was no rocket at 16.8 seconds but all the other ones, KK, KH, and KHK Models were quite fast motorcycles. Even with its` battery, full fenders, large FL type headlight, huge gas tank and full tins the KH was only a half a second slower than the XLCH. I wonder what numbers the KHK would produce? I feel the K`s deserve a lot more recognition for performance than they ever normally receive.
To compliment the extra power the clutch was enlarged from five disc to seven. The primary cover was consequently wider. The cases were strengthened in various places. A stronger primary chain tensioner was made. Second and third countershaft gears were strengthened and received direct oiling. In 1955 countershaft 3rd and mainshaft 2nd gears were superceded to stronger ones and could be returned to HD for credit. Unfortunately due to the torque of the stroker many of them never had a chance. (Compared to state-of-art Andrews gears these early K gears look like they were formed out of a CheezWhiz can) The clutch gear was fitted with a Torrington bearing in place of the bronze bushing previously used. The cam, primary and countershaft covers were all factory polished. A one-way valve now returns excess primary oil to the crankcase. Speedster handlebars, an option in `53, come standard with the Buckhorns optional. The front forks now have rubber boots covering the tubes instead of chrome covers. The seat has been re-designed and is similar to the Model 165. The brake shoes went from aluminum to pressed steel construction. The lining-type has been changed. A new oil-pressure switch was used. With the solid engine sprocket standard, a new-design compensating sprocket was available as an option. 1952 and 53 frames were recognizable by their hollow foot peg mount tubes. For 54 they are solid. Also the rake and trail was slightly changed and the steering neck beefed up for better stability. The gas tank emblems were the same but the extra trim was all dropped. The rear shock absorbers now had chrome covers and tops in place of the Royalite plastic ones. The front fender carried a 50th Anniversary Medallion on top in front. Facts and figures on the KH: The gearing was as follows. Engine sprocket-30, Clutch- 59, Countershaft-22 and Rear Wheel-49 teeth. Gear ratios were 1st- 11.55, 2nd- 8.35, 3rd- 6.37, with a final 4th- 4.58 to 1. Standard tires and wheels were Goodyear or Firestone 19" by 3.25" front and rear. Optional at no extra charge were the same combinations in 18". For a slight additional charge you could order a Goodyear Grasshopper 18" by 4.00" on the rear only. Ignition timing was 19/64" BTDC & 11/32" BTDC for the KH & the KHK respectively, with the spark fully advanced at the twist grip. The Cold Valve Tappet Clearance is .004" intake and .006" exhaust. Golden Anniversary KHs and KHKs were available in the following standard colors: Pepper Red, Glacier Blue, Forest Green, Anniversary Yellow and Daytona Ivory. For no extra charge the tanks could of been ordered with one color and the fenders another. The new KH and KHK motorcycles were headline making motorcycles, representing the best of 50 years of Harley Davidson producing fine American motorcycles.
Hot rodding is alive and well in the USA and in 1955 Harley Davidson is right there with the KHK. Offering "Exceptional performance, that extra tremendous acceleration and that burst of power and speed the instant you touch the throttle on the KHK for 1955." Besides all the normal hand built KHK goodies the 55 offered mirror polished ports and cylinder heads, including the outside of the heads. The Factory advised to order yours early, as "A special model like the KHK is not produced in the normal channels of production. To get that extra horsepower takes time and loving care. The quantities, that can be produced, are rather limited and sufficient time must be allowed to fill orders. The extra net charge for this model is modest in comparison with its` extra performance and the joy it will bring to the fortunate owner." ($68; Some quotes from a 55 sales ads.) Sounds enticing, to say the least. To help transmit this fine power more reliably and to expedite transmission repair the 55 received stronger cases with a `trap door` design built in. This allowed complete overhaul of the transmission through the primary side without having to split the cases as with earlier models. This was actually a running change in 54. Better lubrication of the mainshaft right bearing is achieved by casting a pocket in the case to collect and feed oil to this bearing. Once again transmission gears are improved for strength. C-shaft third and M-shaft second are now forged from 4615 steel, an improvement over the previously employed 8617 bar stock. Other changes include: Stronger right side transmission case, longer shifter retaining bolt on access door holds tighter, larger starter gear retaining nut, steel wear plate installed between kicker shaft and cases and a larger key is used on the flywheel sprocket shaft. Transmission and engine specs remain the same except more fine tuning on the motor and C-shaft sprocket size went from 21 to 22 teeth. Stock wheels are now 18" with 18" by 3.50" tires std. and larger ones optional. The C 1026 steel tubing used in previous frame construction is replaced with chrome moly for 55. The frame has a slight neck angle change and for the first time re-enforced front downtubes. This was complimented with one inch shorter fork tubes resulting in one inch of increased trail. This improved handling. To keep the front fender's duck tail from hitting the front Safety Guard it was simply cut off. To help handle the massive torque the rear wheel hub was greatly increased in size and the rear spokes were up-graded to BigTwin size. Earlier wheels were being torn apart from the torque. An oil port in the clutch cable was introduced for ease of lubricating. The speedometer head size is increased for durability and accuracy. Previous speedos had short head life and bouncy action. The jewel for the pivot shaft has been increased in hardness and a spring dampener added. The entire speedo is now rubber mounted as is the internal mechanism. The steering dampener is changed with a tension spring added to hold the adjustment. The spark and tool box cover studs have been increased in size. A re-designed Buddy Seat is offered with more padding and a Royalite cover replacing the leather one. Gas tanks remain the same except the emblems now carry the HD V-`swoosh` emblems. The front fenders carry either a KH or KHK 1955 Medallion. 1954 facts and figures are carried over to 55, except noted above. The 1955 KHs and KHKs were available in the following colors: Brilliant Black, Aztec Brown, Atomic Blue, Glamorous Hollywood Green, Pepper Red, Anniversary Yellow and Silver or White for Police duty. As before, tanks can be ordered in one std. color and fenders another. For $10 extra you could get the Hollywood Green paint on the tank, fenders and spark coil cover and oil tank. The 1955 Ks were American-made middleweights with distinct features and advantages over all similar-type motorcycles.
1956: The transportation scene in America is changing fast with some 80,000 miles of Super Highways constructed, allowing the public and the 56 KH Sport and KHK Super Sports riders a whole new playing field. All the Ks are now quite re-fined and have enjoyed success, on and off the race track and in many forms of competition. The factory KR racers have dominated the National Championships, winning every class `C` race with the efforts of brave men like Joe Leonard, Brad Andres and others. Joe was factory backed, while Brad came from a racing family with years of experience. HD enjoyed their success either way, as they both rode KRs. Technical input for reliability and performance was born at the race track and lives in the new KHK Super Sports model. The newly popular entertainer Elvis Presely chose a Pepper Red KH for his first Harley V-Twin and was pictured astride it on the cover of The Enthusiast magazine. The new 56 Model Ks ran more mechanically reliable and handled the road better than ever. The 56 is lower and sleeker looking thanks to major changes including an all newly designed Chassis with a much lower center of gravity. Powerplant refinements include a new chemically treated cellulose Air Filter element with a center holdown screw securing the cover and sealing against dust much better than the previous J-Slot type. Polished heads, intake and exhaust ports increase flow and resist carbon deposits. The Oil Pump has been made more reliable and has increased oil return capability to avoid oil stacking in the crankcase. It has a woodruff key replacing the pin and the relief valve has been eliminated to avoid the oil tank draining into the crancase while the motorcycle is parked. The Oil Tank now has a heavy metal protector on the bottom to guard against drivechain damage and a cutout to allow clearance for the new Chainguard and chain angle due to the rear wheel traveling higher into the fender cavity. The Carburetor now sports a bracket to help secure against vibration and loosening of the intake manifold nuts. The Kick Starter crank gear plate is stronger. The Transmission Gears have more beef again. The mainshaft second and third gears and the countershaft second and third gears have larger tooth sections resulting in higher beam strength. The mainshaft second gear engaging dogs are increased in size and number, from four to five. The third gear dogs are also huskier. The forging process has also been changed to make these gears tougher. The Mainshaft was also beefed up mid-year. Major changes in the newly designed Chassis include a sturdier 1' raised Steering Neck, 9/16" shorter rear Shock Absorbers, stronger Seat Casting with lower Seat position and stronger upper Shock attaching area and Shock Mounts. All this plus new larger Shocks with more oil capacity and nice Chrome covers, stronger Swingarm coupled with 18" Wheels front and rear and Speedster Handlebars equals a lower, better handling Model K. The new stance brings a change in the top mount of the Safety Guard. Spring steel Cable Guides route them securly in the handlebar clamp area. The new Frame Blueprint remains basically the same through 1966. The 1956 Frame is one year only, as it has a Cast Upper Engine Mount while the 1957 and later have a Fabricated Steel Mount of basically the same dimensions. Frame assembly line Date codes are found on the right side of the Seat Casting, with the letter representing the month and the number the year. An example would be `6A` meaning January 1956. All 56 frames I have seen have a factory flattened backbone above the rear cylinder head in anticipation of the extra clearance needed for the enevitable switch from Flathead to Overhead Valve type cylinder heads. This plan to use the OHV layout was actually developed pre 1952K. A working 60 Degree OHV design was dropped in favor of the known 45 Degree Side Valve design. Adjustments for the OHV were now happening. Fuel Tanks were slightly different for 56, utilizing a Rubber Hose crossover piping in place of the earlier Fitted Copper type. Mid-56 Tanks carry .5 gallon less fuel due to Rocker Box Clearance built into the bottom section. This is a half year tank. It has the clearance indents for OHV, yet retains the Fuel Filter Valve on the left for Flatheads, and has the 55-56 V-Swoosh emblem mounts. The 1956 KH and KHKs feature a racy slash panel section under the tank emblems. The 56 had a one year only rear Hub Bearing set up using Torrington needle bearings. The 55 Big Twin Taillight has been adopted for the K for 56, featuring a Lucite Lens with a built in magnifier section directly over the bulb. All other specifications remain basically the same as previous models. 1956 KH and KHKs were available with the following color combinations: Pepper Red with White slash, Atomic Blue with the new Champion Yellow slash, Champion Yellow with Black slash and Black with Champion Yellow slash. For an additional $5 you could order Flamboyant Metallic Green with White slash. The 1956 Ks were more refined than ever, and to recieve extra recognition the 1956KHK Models carried a special decalcomania in color carrying the `KHK` letters on a Shield with crossed Checkered Flags at the top, placed on the sides of the oil tank and tool box. "Happy and proud indeed will be the owners who ride these special KHKs in 1956" sayeth the Factory.

THE HISTORY OF THE SPORTSTERcontributions by: docjimbob, Tim Schumacher, Tom Riccio, & Kev Maher and Bruce's Harley Page (check for History on all HD models).

The Sportster XL was introduced as "a modern, up-to-date power plant."
55cid 7.5:1 Compression, hemi-spherical style heads, 90 degree valve angle, 4 cams
Production Information:
XL (1983), $1,103
XLH introduced with higher compression and larger valves
Camshaft gears became integrated with the camshafts, eliminating the need for a woodruff key.
Drive gearshaft was enlarged .125 in.
Drive gear and second gear support shaft was enlarged .125 in and had 8 splines (instead of 6).
Choke control lever moved from left side to the air cleaner.
Heavier clutch cover and new gasket.
New oil resistant clutch hub seal and gearshaft o-ring.
Two brush generator.
Optional turn signals and 1 in over suspension.
The XLC & XLCH (Competition/California Hot)
Larger ports and valves
High domed pistons
Light ended tappets
Magneto ignition
Production Information:
XL (579), $1,155
XLH (711)
XLCH (239)
New dual exhaust on XLH with twin mufflers.
Nacelle headlamp on XLH
5 � in headlamp with eyebrow on XLCH
Trip-o-meter on XLCH
Nylon chain tensioner
Single switch ignition on left fork
Valanced front fender
End relieved connecting rod bearings
14.5 sec � mile (90 mph)
Production Information:
XL (42), $1,175
XLH (947), $1,200
XLCH (1059), $1,285
New shock absorbers.
Production Information:
Sportsters (2,765) XLH $1,225 XLCH $1,310
Creased edge on fuel tank.
Production Information:
Sportsters (2014) XLH $1,250 XLCH $1,335
Aluminum upper triple tree.
XLR appeared for TT racing.
Production Information:
Sportsters (1998) XLH $1,250 XLCH $1,335
Both XLH & XLCH got 1.323:1 3rd gear ratios (were 1.381)
Final ratio 5.56:1 on the H
Final ratio 5.85:1 on the CH
XLCH got "shorty duals"
XLCH got an ignition key and improved magneto/coil
14.3 sec � mile (92 mph)
Production Information:
XLH (432), $1,270
XLCH (1,001), $1,355
Chrome panel for XLCH lower fork bracket.
New graphic for the XLH (oil tank).
Full width aluminum brake drum in the front.
Aluminum tappet guides.
Production Information:
XLH (810), $1,295
XLCH (1950), $1,360
XLH and XLCH received a 12 volt electrical system.
XLH got automatic spark advance.
Racing-type ball end levers.
High fidelity horn.
New shocks
3.7 gal fuel tank
Production Information:
XLH (955)
XLCH (2815)
P Cams, race developed intake ports, jumbo valves -> 60 hp
Tillotson diaphragm carb
"Ham-can" air cleaner
Carb heat insulator
Hexagonal tank badge.
Production Information:
XLH (900) $1,415XLCH (3,900) $1,411
XLRTT (25)
Electric start option.
New shocks
Production Information:
XLH (2,000) $1,650
XLCH (2,500) $1,600
New forks (damping and travel) and the fork boots were canned.
Kick start was dropped from the XLH.
Restyled primary cover.
Peanut tank was an option on the XLH
Production Information:
XLH (1,975) $1,650
XLCH (4,900) $1,600
First use of the exhaust crossover pipe (increases hp by 5 to 58 hp) with stacked duals
New head castings.
Safety bead wheel rims.
Production Information:
XLH (2,700) $1,765
XLCH (5,100) $1,698
XLH got the headlamp eyebrow of the XLCH
Optional boat tail (again in 71)
Magneto ignition on the XLCH replaced with XLH's points/coil.
First year for XR-750
Production Information:
XLH (3,033)
XLCH (5,527)
Wet clutch with single spring.
Points and condenser moved behind plate on timing case cover.
Production Information:
XLH (3,950)
XLCH (6,825)
The 61 cid (called a 1000cc) XL replaced the 900.
Rated for 61 hp, 9:1 CR, 110+mph, 13.38 sec � mile (97.7 mph), and 43 mpg.
Bendix/Zenith carb.
Wet clutch.
New oil pump.
Oil tank placed near chain
Seat is thinner w/less padding.
Production Information:
XLH (7,500) $2,120
XLCH (10,650)
First AMF production Harley
Mandatory turn signals.
New 35mm Kayaba forks, single disc front brakes.
Production Information:
XLH (9,875)
XLCH (10,825)
Throttle used return springs.
Production Information:
XLH (13,295)
XLCH (10,535)
XR (100)
Left hand side gear shifting, right hand side rear brake (Fed mandated)
New 35mm Showa forks.
Production Information:
XLH (13,515)
XLCH (5,895)
Production Information:
XLH (12,844)
XLCH (5,238)
New cases to accommodate the left side shifting.
Frame designed for removal of oil pump with engine in frame.
XLT (touring) became available
included thicker seat
3.5 gallon tank
touring handle bars
saddlebags from FLH
geared higher
XLCR was introduced at Daytona (available again in 78).
cast aluminum wheels
fiberglass tail section w/solo seat
wrinkle black engine paint
bikini fairing
black siamese exhaust
dual disc front brakes
low bars
black paint scheme [on everything]
4 gallon gas tank
68 horses, 9:1 compression, 110 mph
Production Information:
XLH (12,742)
XLCH (4,074)
XLT (1,099)
XLCR (1,923) $3,623
Cast wheels option
Front dual disc brakes
Electronic ignition
Battery and oil tank moved inboard
HD 75th anniversary model XLH
Midnight black w/gold trim
anniversary graphics
gold aluminum wheels
Production Information:
XLH (11,271)
XLH Anniv model (2,323) $3,127
XLCH (2,758) $3,370
XLT (6)
All models got the XLCR frame and exhaust (Siamese).
XLT was dropped from the product line.
Kick starter was dropped.
Disc brakes front and rear.
Hugger model available for the first time.
Last year for XLCH
New model XLS appeared:
Extended forks
16" rear wheel
siamese exhaust
drag bars on 3.5" risers
sissy bar w/leather pouch
highway pegs
2 piece seat
chromed rear sprocket
Production Information:
XLH (6,525)
XLCH (141)
XLS -(5,123)
XLCR (9) (?leftover '78's?)
A 16 in wheel replaced the XLH 18 in.
Production Information:
XLH (11,841) $5,867
XLS (2,926)
Buy back from AMF
wire or cast wheels options, 16" or 18" rear wheel options
buckhorn handlebars
shorty dual exhaust
3.3 gallon, 2.2 gallon tank optional.
shorter front forks
3.3 gallon optional.
Production Information:
XLH (8,442)
XLS (1,660)
Lighter frame
oil tank repositioned
Thicker head gasket w/lower 8:1 compression
Larger rear disc
XLS repositioned the battery
Production Information:
XLH (5,015)
XLS (1,261)
high bars
vacuum advance (VOES?)
3.3 gallon tank option
new seat
less restrictive exhaust.
New model XLX-61: (built to sell for $3,995)
solo seat
peanut tank
staggered dual exhaust
speedo only
9 spoke wheels
vacuum advance (VOES?)
satin finish cases. {only year}
six coil springs in clutch
156 watt generator
loose output roller tranny
output shaft oil seal secured by a bolt on cover
3 generator drive gears
10" dual front disc brakes.
New model - XR-1000, based on XLX chassis
aluminum SR style heads w/intake ports on right, exhaust on left
polished and bored by Jerry Branch
helicoil inserts where rocker boxes bolt to head,
9:1, XR pistons
light aluminum pushrods
eccentric rocker shafts adjust valve lash
iron cylinders (shortened half an inch to make room for the 'Branch' heads)- w/through bolts
vacuum advance-V-fire III breaker less ignition
twin 36mm Dell'Orto carbs
satin textured cases
9 spoke cast wheels
oiled felt air filter
The XR-1000 had 71HP @ 5,600 rpm, 125 mph, 490 lbs
2.5 gallon tank, 2.5 quart oil capacity $6,995.
Production Information:
XLX-61 (4,892) $3,995
XLH (2,230)
XLS (1,616)
XR-1000 (1,018) $6,995
Diaphragm spring clutch (mid year)
Generator replaced by the alternator. (mid year)
XLH used the Peanut tank again.
XR, improved brakes, orange/black HD racing color option
XLH/X/S Single (larger) front disc.
Production Information:
XLX-61 (4,284)
XLH (4,442)
XLS (1,135)
XR-1000 (759)
Production trimmed in anticipation of the Evo XL.
Production Information:
XLX-61 (1,824)
XLH (4,074)
XLS (616)
First year of the Evo Sportster
came in 883 and 1100cc flavors
XLX frame
Aluminum heads and cylinders
hydraulic lifters
34mm fixed-venturi Keihin carb
powder coat frame paint
cast aluminum wheels
solo seat
low bars
speedo only
turn signals double as running lights
30" seat height
Upgrade package=special paint and trim.
Production Information:
XLH 883 (8,026) $3,995XLH 883 (2,322) (upgrade)XLH 1,100 (3,077) $5,199XLH 1,100 (954) 'Liberty'
Sportsters 30th Anniversary
first year for the Evo Hugger:
The fork tubes were shortened 2"
revised shock angle
a softer seat at 26.75", (1.75" lower than standard)
Production Information:
XLH 883 (4,990)
XLH 883 (2,106) 'Hugger'
XLH 883 (2,260) (upgrade)
XLH 1,100 (4,018)
XLH 1,100 (600) 'Anniversary'
new 39mm Fork Tubes replaced the older 35mm unit
new 40mm constant velocity Keihin slide carb
first year for the 1200 (replacing the 1100)
Production Information:
XLH 883 (5,387)
XLH 883 (4,501) 'Hugger'
XLH 883 (1,893) 'Sportster Deluxe'
XLH 1,200 (4,752)
kickstand repositioned father rearward
price increase jumped from $3995 to $3999 for the base model 883
Production Information:
XLH 883 (6,142)
XLH 883 (4,467) 'Hugger'
XLH 883 (1,812) 'Sportster Deluxe'
XLH 1,200 (4,546)
new paper air filter and paint options
40mm Keihin carb - constant velocity w/accelerator pump
Production Information:
XLH 883 (5,227) $4,250
XLH 883 (4,040) 'Hugger'
XLH 883 (1,298) 'Sportster Deluxe'
XLH 1,200 (4,598)
5 speed tranny replaced the 4 speed
belt drive replaced chain on 883 deluxe and 1200 models
hydraulic lifters were replaced with automotive type units
oil pump given internal cast feed lines
breather system moved from the crankcase to the heads (umbrella valves)
alternator moved from behind clutch to the crankshaft
primary cover redesigned
new foot peg mounts
old Dunlop k-291 tires replaced with K402's
Self canceling signals
right side timing hole
tappet blocks, rear motor mount, oil filter integrated with case
one piece push rod tubes
Production Information:
XLH 883 (4,922) $4,359
XLH 883 (3,487) 'Hugger'
XLH 883 (3,034) 'Sportster Deluxe'
XLH 1,200 (6,282) $6,245
Hugger model made even lower
standardized hand controls
Production Information:
XLH 883 $4,499
XLH 883 'Hugger' $5,075
XLH 883 'Sportster Deluxe' $5,559
XLH 1,200 $6,400
belt drive now on all Sportster models
Production Information:
XLH 883 $4,775
XLH 883 'Hugger' $5,420
XLH 883 'Sportster Deluxe' $5,820
XLH 1,200 $6,800
Oil tank revised (visually identified by relocated oil drain line which now runs to the frame instead of nipple on underside of battery tray)
Derby cover revised from small cover over center of clutch to large 4-bolt cover (with this came a new quick-release clutch cable)
Revised rear struts with chromed steel covers.
New electrical system (wiring harness/weatherproof electrical connectors, new electrical component tray under the seat)
883s got an aluminum lower triple clamp which was previously stock on only the 1200�s
New Larger standard gas tank (3.25 gal) on 1200 models
Vacuum operated petcock added to Sportster line
Ignition switch moved to steering column (because of petcock)
Switched to electric speedo
Production Information:
XLH 883 $4,995
XLH 883 'Hugger' $5,700
XLH 883 'Sportster Deluxe' $6,120
XLH 1,200 $7,200
Switchgear revised, more rounded style
First year for 1200 Custom and Sport models
Production Information:
XLH 883 $5,095
XLH 883 'Hugger' $5,760
XLH 1,200 $7,360
XLH 1,200 '1200C Custom' $7,910
XLH 1,200 '1200S Sport' $8,360
New Larger standard gas tank (3.25 gal) on 883 models
Revised ignition system (single fire)
1200S gets dual-plug heads (along with hotter cams)
First year of the 883C
First year for sealed wheel bearings
First year for 4-piston calipers
Pressed together flywheel assembly (supposed to be stronger and hold it's trueness better)
First year for the 883R
Introduction of the bullet-style turn signals across the line
Final year for solid mount models
New style mirrors.
Special Harley-Davidson 100th Anniversary paint/badges
Engine is rubber mounted
Trap door transmission eliminated (cases must now be split to access transmission).
Oil tank is mounted further under the seat
Seat height is lowered by an inch
Rear tire width increased to 150 mm
Custom models get 4.5 gallon gas tanks
New air cleaner cover
Brake calipers, master cylinder, switch housings and handgrips replaced, now exclusive to Sportster models.
Swing arm & rear wheel re-designed to accommodate 1" rear axle.
Que comecem os trabalhos !
Related Posts Plugin for WordPress, Blogger...
